MOD - Creating a Planet 0.95
|
|
| SpaceEngineer | Date: Tuesday, 28.08.2012, 18:38 | Message # 46 |
 Author of Space Engine
Group: Administrators
Russian Federation
Messages: 4800
Status: Offline
| Arron17, your should type
NoAtmo true
if you want to prevent SE to generate procedural atmosphere.
|
| |
| |
| Arron17 | Date: Tuesday, 28.08.2012, 18:47 | Message # 47 |
|
Observer
Group: Users
United Kingdom
Messages: 18
Status: Offline
| Quote (SpaceEngineer) Arron17, your should type
NoAtmo true
if you want to prevent SE to generate procedural atmosphere.
Where do I put this?
I tried in the planet parameters and in the atmosphere parameters and it made no difference.
Intel Core i3-330m, 4GB RAM, ATi Radeon 5650 1GB
|
| |
| |
| HarbingerDawn | Date: Tuesday, 28.08.2012, 19:36 | Message # 48 |
 Cosmic Curator
Group: Administrators
United States
Messages: 8717
Status: Offline
| Quote (Arron17) I tried in the planet parameters and in the atmosphere parameters and it made no difference.
Type NoAtmosphere true in the general parameters section (same place that radius, class, etc. go).
All forum users, please read this!
My SE mods and addons
Phenom II X6 1090T 3.2 GHz, 16 GB DDR3 RAM, GTX 970 3584 MB VRAM
|
| |
| |
| LordHaHa | Date: Friday, 21.09.2012, 01:44 | Message # 49 |
 Space Tourist
Group: Users
United States
Messages: 23
Status: Offline
| I've got these weird spikes on some of the terrain on my custom planet. They look cool from a distance but up close they are UGLY. Any thoughts on how to repair this one? Screens below the line.
LordHaHa
Edited by LordHaHa - Friday, 21.09.2012, 01:44 |
| |
| |
| SpaceEngineer | Date: Friday, 21.09.2012, 17:17 | Message # 50 |
|
Author of Space Engine
Group: Administrators
Russian Federation
Messages: 4800
Status: Offline
| This looks like mountains or hills or canyons with a too high frequency.
|
| |
| |
| LordHaHa | Date: Saturday, 22.09.2012, 06:46 | Message # 51 |
|
Space Tourist
Group: Users
United States
Messages: 23
Status: Offline
| Quote (SpaceEngineer) This looks like mountains or hills or canyons with a too high frequency.
Yeah, that was the problem. Mountain freq was around 300 something and Hills freq was 500 something...but Dunes freq was 700! I turned them all way down (150 mount, 66.7 hill, 78 dunes) and that has fixed everything. Funny thing this became an issue as this was originally a procedural planet. Of course I also dropped the radius down a lot to get the gravity up, so that might have effected things. Also there was way too much terracing after fixing that problem, so I had to add "terraceProb" to the file and halve the default value.
But thanks for the help out, its pretty much done now.
LordHaHa
|
| |
| |
| neutronium76 | Date: Tuesday, 25.09.2012, 22:11 | Message # 52 |
 World Builder
Group: Users
Greece
Messages: 718
Status: Offline
| Hello. I am trying to create the planetary system from the movie ''Prometheus''. I found out that this system actually exists in SE: its ζ2 ret and in particular its the ζ2 ret A3 gas giant and its moon A3.2 (the famous LV_223 planet of the ''Engineers'') that I am after. So the gas giant is upposed to have a ring system around it. Unfortunately both zeta 2 reticuly A3 and its moon A3.2 are procedural planets in SE. So what do I have to do in order to edit them? Can I somehow export them (as scripts and not as textures) in an .sc file and then add the rings to the gas giant. And would I be able to import them back to SE and replace the procedural ones? Because I am afraid there will be dublicates if I export them, edit them and re-inport them.
PC1:Core i7 970@3.34GHz, 6 cores/12 threads, 12GB DDR3 RAM@1.34GHz, 2x(SLI) GTX-580 GPUs 3GB VRAM(GDDR5)@1GHz, OS:Win7x64SP1
PC2:Core2Quad X9770@3.2GHz, 2 cores/4 threads 4GB DDR2 RAM@1GHz, GTX-285 GPU 1GB VRAM(DDR3)@1.24GHz, OS:WinVistax64SP2
|
| |
| |
| HarbingerDawn | Date: Tuesday, 25.09.2012, 22:31 | Message # 53 |
|
Cosmic Curator
Group: Administrators
United States
Messages: 8717
Status: Offline
| neutronium76, if you export the system and use that code to create a new catalog file or add to an existing one, it will replace the existing system; there will be no duplicates.
All forum users, please read this!
My SE mods and addons
Phenom II X6 1090T 3.2 GHz, 16 GB DDR3 RAM, GTX 970 3584 MB VRAM
|
| |
| |
| neutronium76 | Date: Wednesday, 26.09.2012, 10:43 | Message # 54 |
|
World Builder
Group: Users
Greece
Messages: 718
Status: Offline
| Ok I exported the system from the editor using the ''export system'' function, I went to cache/export folder and opened the newly created ''ZET2 ret.sc'' file with notpad. I than copy-pasted the ring code from :
Code
Rings // Rings tag
{
// Texture parameter is commented out, becuase
// this planet use procrdural generation of texture
//Texture "Icarus-rings.*" // Rings texture
InnerRadius 8318.5 // Inner raduis of rings system in km
OuterRadius 12438.3 // Outer radius of rings system in km
RotationPeriod 43.3 // Rings rotation period in hours
RotationOffset 60.0 // Rings rotation phase in degrees
FrontBright 1.0 // Direct lighting brightness
BackBright 5.0 // Back lighting brightness (scattering)
Density 1.0 // Density (opacity)
Exposure 2.0 // Global brightness
}
section and I used the planet radius as a guide to change the inner and outer radius parameter for planet A3. But unfortunately there are no rings shown in SE  . I remember I copied the entry in universe.cfg under planet section so what am I doing wrong?
I enclose both zeta2 ret.sc and universe.cfg for you people to check:
PC1:Core i7 970@3.34GHz, 6 cores/12 threads, 12GB DDR3 RAM@1.34GHz, 2x(SLI) GTX-580 GPUs 3GB VRAM(GDDR5)@1GHz, OS:Win7x64SP1
PC2:Core2Quad X9770@3.2GHz, 2 cores/4 threads 4GB DDR2 RAM@1GHz, GTX-285 GPU 1GB VRAM(DDR3)@1.24GHz, OS:WinVistax64SP2
|
| |
| |
| SpaceEngineer | Date: Wednesday, 26.09.2012, 12:50 | Message # 55 |
|
Author of Space Engine
Group: Administrators
Russian Federation
Messages: 4800
Status: Offline
| You made an recursive link:
Code
Barycenter "ZET2 Ret"
{
ParentBody "ZET2 Ret"
...
}
You should rename the barycenter (for example to "ZET2 Ret barycenter") or just don't use it at all - in reality ZET2 Ret is a singe star. So remove barycenter, stars A and B and star's B planetary system, then make all planet of star A rotating around ZET2 Ret, and rename them from A1, A2, A3 etc to simply 1, 2, 3.
|
| |
| |
| RedKing | Date: Wednesday, 26.09.2012, 16:36 | Message # 56 |
 Observer
Group: Newbies
United States
Messages: 6
Status: Offline
| I'm having a similar problem to neutronium76 with the rings, though I also get the opposite.
Code
Planet "Turis"
{
ParentBody "Theral"
Class "Desert"
Mass 7.177274
Radius 11043.636
Obliquity -2.975179e-008
EqAscendNode 19.24333
Albedo 0.3
Color (1.000, 1.000, 1.000)
Surface
{
Style 0.5847038
Randomize (0.255, 0.597, -0.793)
colorDistMagn 0.04210091
colorDistFreq 690.4531
detailScale 36233.26
colorConversion true
seaLevel 0.05326123
snowLevel 0.98869
tropicLatitude 0
icecapLatitude 0.5
icecapHeight 0.07414196
climatePole 1
climateTropic 0.45
climateEquator 0.625
tropicWidth 0.07
mainFreq 0.9978861
venusFreq 0.4354896
venusMagn 0.3078657
mareFreq 1.34754
mareDensity 0.200675
erosion 0
montesMagn 0.2214149
montesFreq 356.9006
montesFraction 0.910012
dunesMagn 0.04610201
dunesFreq 47.51549
dunesFraction 0.00378642
hillsMagn 0.1414673
hillsFreq 600.1253
hillsFraction -0.00378642
hills2Fraction 0
canyonsMagn 0.0403211
canyonsFreq 140.2407
canyonFraction 0
cracksMagn 0.1326861
cracksFreq 0.5194907
cracksOctaves 0
craterMagn 0.6217116
craterFreq 18.39561
craterDensity 0.6479576
craterOctaves 9.09466
craterRayedFactor 0
colorSea (0.320, 0.240, 0.210, 0.000)
colorShelf (0.290, 0.220, 0.200, 0.000)
colorBeach (0.820, 0.740, 0.570, 0.000)
colorDesert (0.810, 0.640, 0.450, 0.000)
colorLowland (0.770, 0.580, 0.400, 0.000)
colorUpland (0.620, 0.330, 0.170, 0.000)
colorRock (0.220, 0.200, 0.200, 0.000)
colorSnow (1.000, 1.000, 1.000, 1.000)
colorLowPlants (0.770, 0.580, 0.400, 0.000)
colorUpPlants (0.620, 0.330, 0.170, 0.000)
BumpHeight 20
BumpOffset 4
DiffMapAlpha "Ice"
SpecularBright 0.3
SpecularPower 150
DayAmbient 0.07
Lommel 0
Exposure 2
}
Atmosphere
{
Model "Earth"
Height 352.1818
Density 4.451852
Pressure 0.007965851
Bright 3
Opacity 0.3
SkyLight 1
EclipseBright 100
EclipseColor (0.700, 0.500, 0.200)
}
Orbit
{
SemiMajorAxis 9.2245788
Eccentricity 0.05632827
Inclination 133.9931
AscendingNode 40.17454
ArgOfPericenter 157.2654
MeanAnomaly 340.7682
RefPlane "Ecliptic"
}
}
Despite not having codes for rings, the planet still shows rings in the simulator. What am I doing that I'm not suppose to.
I also noticed that adding the ring code seems to disable the rings.
|
| |
| |
| neutronium76 | Date: Wednesday, 26.09.2012, 17:01 | Message # 57 |
|
World Builder
Group: Users
Greece
Messages: 718
Status: Offline
| Quote (SpaceEngineer) You should rename the barycenter (for example to "ZET2 Ret barycenter") or just don't use it at all - in reality ZET2 Ret is a singe star. So remove barycenter, stars A and B and star's B planetary system, then make all planet of star A rotating around ZET2 Ret, and rename them from A1, A2, A3 etc to simply 1, 2, 3.
But in the movie it looks like a multiple star system or a small diffuse star cluster:
If I remove Star A, which Star the planets of star A will orbit around?
So can I remove everything and keep only the star A, renamed to zet 2 reticuli and its planets, renamed to 1,2.. etc..?
PC1:Core i7 970@3.34GHz, 6 cores/12 threads, 12GB DDR3 RAM@1.34GHz, 2x(SLI) GTX-580 GPUs 3GB VRAM(GDDR5)@1GHz, OS:Win7x64SP1
PC2:Core2Quad X9770@3.2GHz, 2 cores/4 threads 4GB DDR2 RAM@1GHz, GTX-285 GPU 1GB VRAM(DDR3)@1.24GHz, OS:WinVistax64SP2
Edited by neutronium76 - Wednesday, 26.09.2012, 17:19 |
| |
| |
| HarbingerDawn | Date: Wednesday, 26.09.2012, 17:22 | Message # 58 |
|
Cosmic Curator
Group: Administrators
United States
Messages: 8717
Status: Offline
| Quote (RedKing) Despite not having codes for rings, the planet still shows rings in the simulator. What am I doing that I'm not suppose to.
If you want to suppress the generation of rings, atmospheres, clouds, and/or oceans on a planet, you need to add the parameter NoRings true, NoAtmosphere true, NoClouds true, and/or NoOcean true to the planet's script.
All forum users, please read this!
My SE mods and addons
Phenom II X6 1090T 3.2 GHz, 16 GB DDR3 RAM, GTX 970 3584 MB VRAM
|
| |
| |
| scavenger | Date: Wednesday, 26.09.2012, 22:39 | Message # 59 |
 Space Tourist
Group: Users
France
Messages: 25
Status: Offline
| hello
I'm a definitive fan from the Riddick series. Since I discovered this marvelous simulator, I'm at least able to find this f.....g system called M344/G !!!
extract from http://riddick.wikia.com/wiki/M-344/G_system :
Quote
The star system in which Pitch Black occurs. It is a triple star system with three planets. The second planet is mostly a desert, and where Pitch Black takes place.
Don't pay attention to the stupid double ring of the giant backside...
the system I'm talking about is this one, right from the movie :
day :
night :
now that's not that difficult to find a tri star system... I found in one of the place examples a 5 star system: RSC 8403-1599-0-0-4
I easily exported & modified it, positioned in space too (derivation from an existing star system), BUT how can I import it ??
What I did just by guessing from the other files content is :
- create a custom data\catalogs\stars\M344G.sc
- add it to load inside the config\universe.cfg
- the main parent is a StarBarycenter (found using search F3), if I keep it as Barycenter, to find it I have to add it inside stars120k.txt
- I suppressed all references to asteroids
well when I load the stuff... I find my M344G StarBarycenter & go to it, but with no stars and black planets, and my sub-systems (it's a 3 star system) are scattered around.
I really don't understand, moreover after having lost (or not) 3 hours on it. I need your help dear masters
where do I find information on how to build a multiple star system ?
I just want my star system to be inside MW or Sagitarius, near center
the code i'm working on is too big to fit here
thks !!!!
edit : well i just rode the topic http://en.spaceengine.org/forum/17-338-1 about stars & barycenters, well i'll see that tomorrow
Edited by scavenger - Wednesday, 26.09.2012, 23:45 |
| |
| |
| Solaris | Date: Thursday, 27.09.2012, 01:30 | Message # 60 |
 World Builder
Group: Global Moderators
France
Messages: 731
Status: Offline
| scavenger, I've moved your message here.
|
| |
| |
